1984-1996 Yamaha Outboard Motor Service Repair Manual

Covers: 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996 Yamaha Outboard Motors

• Carbureted models only – full list at bottom of page

Pages: 630
Format: PDF
File size: 161mb
Compatibility: Windows/Mac/Tablet/Smartphone

Get the downloadable PDF service/repair manual for 1984-1996 Yamaha outboard motors. This manual specifically covers carbed models and includes over 600 pages of instructions, photos, and specifications needed to maintain, adjust, troubleshoot, repair and overhaul the motor. It provides hand-on owners with a time-saving technical guide for working on the outboard.

Skip the guesswork and get the reliable information you need to complete your next project with confidence. A download link will be emailed you within minutes, no waiting for shipping!

Topics:

• General Information, Safety, Tools
• Maintenance and Tune-up
• Fuel System
• Ignition and Electrical (including Wiring Diagrams)
• Lubrication and Cooling
• Powerhead
• Lower Unit
• Tilt and Trim
• Remote Controls
• Hand Rewind Starter
• Index

This PDF covers the following outboard models/years:

Carbed models only-

• 2 hp, 1 cyl (43cc), 2-stroke – 1984-96
• 2 hp, 1 cyl (50cc), 2-stroke – 1995-96
• 3 hp, 1 cyl (70cc), 2-stroke – 1989
• 3 hp, 1 cyl (70cc), 2-stroke – 1990-96
• 4 hp, 1 cyl (83cc), 2-stroke – 1984-96
• 4 hp, 1 cyl (103cc), 2-stroke – 1996
• 5 hp, 1 cyl (103cc), 2-stroke -. 1984-96
• 6 hp, 2 cyl (165cc), 2-stroke -. 1986-96
• 8 hp, 2 cyl (165cc), 2-stroke -. 1984-96
• 9.9 hp, 2 cyl (246cc), 2-stroke – 1984-96
• 9.9 hp, 2 cyl (232cc), 4-stroke – 1984-96
• 15 hp, 2 cyl (246cc), 2-stroke – 1984-96
• 20 hp, 2 cyl (395cc), 2-stroke – 1996
• 20 hp, 2 cyl (430cc), 2-stroke – 1996
• 25 hp, 2 cyl (395cc), 2-stroke – 1988-96
• 25 hp, 2 cyl (430cc), 2-stroke – 1990-96
• 25 hp, 2 cyl (496cc), 2-stroke – 1984-96
• 25 hp, 3 cyl (496cc), 2-stroke – 1996
• 28 Jet, 3 cyl (698cc), 2-stroke – 1990-96
• 30 hp, 2 cyl (496cc), 2-stroke – 1984-96
• 30 hp, 3 cyl (496cc), 2-stroke – 1987-96
• 35 Jet, 3 cyl (698cc), 2-stroke – 1987-96
• 40 hp, 2 cyl (592cc), 2-stroke – 1989-96
• 40 hp, 3 cyl (698cc), 2-stroke – 1984-96
• 45 hp, 4 cyl (935cc), 4-stroke – 1996
• 48 hp, 2 cyl (760cc), 2-stroke – 1996
• 50 hp, 3 cyl (698cc), 2-stroke – 1984-96
• 50 hp, 3 cyl (849cc), 2-stroke – 1994-96
• 50 hp, 4 cyl (935cc), 4-stroke – 1995-96
• 55 hp, 2 cyl (760cc), 2-stroke – 1989-95
• 60 hp, 3 cyl (849cc), 2-stroke – 1991-96
• 65 Jet, 3 cyl (1140cc), 2-stroke -1987-96
• 70 hp, 3 cyl (849cc), 2-stroke – 1984-96
• 75 hp, 3 cyl, (1140cc), 2-stroke -1994-96
• 80 hp, 3 cyl, (1140cc), 2-stroke -1994-96
• 80 Jet, V4 (1730cc), 2-stroke – 1987-96
• 85 hp, 3 cyl, (1140cc), 2-stroke -1989-96
• 90 hp, 3 cyl, (1140cc), 2-stroke -1984-96
• 105 Jet, V6 (2596cc), 2-stroke – 1996
• 115 hp, V4 (1730cc), 2-stroke – 1984-96
• 130 hp, V4 (1730cc), 2-stroke – 1988-96
• 140 hp, V4 (1730cc), 2-stroke – 1984-96
• 140 Jet, V6 (2596cc), 2-stroke – 1987-95
• 150 hp, V6 (2596cc), 2-stroke – 1984-96
• 175 hp, V6 (2596cc), 2-stroke – 1984-96
• 200 hp, V6 (2596cc), 2-stroke – 1984-96
• 220 hp, V6 (2596cc), 2-stroke – 1984-87
• 225 hp, 76 deg. V6 (3130cc), 2-stroke -1994-96
• 225 hp, 90 deg. V6 (2596cc), 2-stroke -1987-96
• 250 hp, V6 (3130cc), 2-stroke – 1990-96
